Description
A text description of the key advantages and features of the trailer goes here. Focus on the Benefits of operation to the company using the Trailor. A text description of the key advantages and features of the trailer goes here. Focus on the Benefits of operation to the company using the Trailor. A text description of the key advantages and features of the trailer goes here. Focus on the Benefits of operation to the company using the Trailor. A text description of the key advantages and features of the trailer goes here. Focus on the Benefits of operation to the company using the Trailor.
To enquire about the PTE 3 Axle Low Loader Transporter please call our email us.Specification
- GVM: 40 Tonne
- Deck length: 10,500mm
- Forward length: 9,200mm
- Top Deck: 4,000mm
- Width: 2,500mm
- Load anchorages: 19 per side @ 12t, Top Deck 11 @ 8T, 20Ft container locks
- Deck: 50mm H3 treated pine
- Landing legs: Meritor dual speed wind up legs
- Axle spacing: 1,900mm
- Axles :ROR 17.5 drum axle x3
- Suspension: Weweler air suspension
- Wheels & Tyres: Polished aluminum rims with Kiwi 215 75 17.5 tyres
- Brakes: Knorr Bremse EBS
- Lights: 7 core sealed looms with Hella LED multivolt lighting system
- Skidplate & Kingpin: 1,350mm, 50mm bolt in
- Ramps: 2,800mm long by 950mm wide
- Hydraulics: From truck PTO
- Toolboxes: Under deck both sides and in front of main deck
Options:
- Hydraulic or electric winch
- 40Ft container locks
- Petrol, diesel or electric powerpack
- Wabco EBS
- Smartboard/TIMS module
- Lift axles
- SAF suspension & axles
- Outriggers
- Wide Ramps
